| LED Rating/System Wattage/Rated Power |
: 60W |
| Ingress Protection (IP Rating) as per IS:10322 (Part 1):1982 latest |
: IP65 |
| Warranty for free replacement (in Years) |
: 2 |
| Input operating Voltage range and frequency |
: 140 to 270 V olts AC at 50 Hz+/-2 Hz with auto cutt off at below 120V |
| Rated voltage |
: 230 V AC 50 Hz |
| Total Harmonics Distortion (in %age) |
: ≤ 10 |
| Colour temperature (+/-500K) |
: 6000K |
| Working life for LED (Minimum 50,000 burning hours as per LM-80 report) |
: Yes |
| Colour Rendering Index(CRI) |
: ≥70 |
| Heat sink should be die-cast aluminium along with sufficient heat sink fins to dissipate heat effectively |
: Yes |
| Junction temperature |
: < 85 degC |
| Operating temperature range |
: -20 deg C to +50 deg C |
| The luminaire shall be protected against surges and transients ( Internal) |
: >/=5KV |
| The luminaire shall be protected against surges and transients of >/=10KV (External) |
: Yes |
| Number of electronic control gear (power supplies) |
: 1 No. |
| Length of ISI marked three core wire (shall be provided along with supply of material) |
: 50 cm |
| LED Make |
: OSRAM / NICHIA/CREE / SAMSUNG / SEOUL / LUMILED / PHILIPS / EDISON / SYSKA / LUMENMAX / EVERLIGHT / BRIDGELUX / NATIONSTAR / REFOND |
